Textron Jacobsen HR-5111 User Manual

HYDRAULICS
4203780 First Edition 6-21
6
Mow Circuit (ON) Schematic
See Figure 6-12.
Figure 6-12
1 Operating Pressure Oil from Gear Pump (Section 2) 3 Operating Pressure Oil from Gear Pump (Section 4)
2 Operating Pressure Oil from Gear Pump (Section 3) 4 Return Oil to Oil Cooler and Return Filter
TN1721
Operating Pressure Oil
Return Oil
Inlet or Drain Oil
Relief Valve
3000 psi
CW Outside
Right Wing
Motor
P
1
Right Deck
Valve
2
1.04 ci
3
Hydraulic Oil Tank
0.67"
D
1.04 ci
1.04 ci
1.04 ci
1.04 ci
1.04 ci
1.04 ci
0.67"
0.67"
0.67"
0.67"
0.67"
0.67"
CCW Inside
Right Wing
Motor
CW Inside
Left Wing
Motor
CCW Outside
Left Wing
Motor
CCW Left
Front Motor
CW Center
Front Motor
CW Right
Front Motor
4
Blade Brake Relief
630 psi
A
B
Left Deck
Valve
Front Deck
Valve
Relief Valve
3000 psi
Relief Valve
3000 psi
P
P
D
D
A
A
B
B
Tank Check Valve
Solenoid
Valve
Solenoid
Valve
Solenoid
Valve
T
Blade Brake Relief
630 psi
T
Blade Brake Relief
630 psi
T
