HYDROSTATIC POWER TRAIN
4203780 First Edition 5-73
5
Differential Assembly
Disassembly and Inspection
See Figure 5-80.
Figure 5-80
1 Differential Housing, Right 5 Differential Lock Collar 9 Ball Bearing (2) 13 Differential
2 Screw (8) 6 Shim (As Required) 10 Plug (2) 14 Differential Housing, Left
3 Breather 7 Shim (As Required) 11 Hex Head Bolt (8) 15 Seal
4 Dowel Sleeve (2) 8 Shim (As Required) 12 Ring Gear 16 Drain Plug
TN1787
8
2
10
4
1
9
6
4
12
2
5
7
6
7
8
9
11
13
14
15
16
3
