ENGINE
4203780 First Edition 3-3
3
Component Location
Kubota V2203-DI-B
See Figures 3-1 and 3-2.
Figure 3-1: Component Location—Right Side
1 Hydraulic Oil Cooler 7 Oil Pressure Sending Unit
2 Radiator 8 Starter Motor
3 Thermostat 9 Alternator
4 Air Cleaner Assembly 10 Fan Drive Belt
5 Coolant Overflow Reservoir 11 Engine Temperature Sensor
6 Hydraulic Oil Filters 12 Fuel Pump
1
7
9
5
10
11
8
4
2
3
6
12
TN2003, TN2036
