HYDRAULICS
4203780 First Edition 6-5
6
Figure 6-2: Component Location—Right Side
13 Lift Valve 14 Right Wing Cutting Unit Motor (2) 15 Right Wing Lift Cylinder
3
4
2
1
TN1769
13
15
14
