ELECTRICAL
4203780 First Edition 4-7
4
Miscellaneous Symbols
Enclosure
(cabinet, housing, etc.)
Wires (crossing but not
connected)
Ground (to earth) Wiring Connections
Ground (to chassis) Coil
Direct Current (DC)
(as shown on an oscilloscope)
Battery
Alternating Current (AC)
(as shown on an oscilloscope)
Diode
Resistor Pin and Socket Connector
