146
FUNCTION SETTING USING SETTINGS SCREEN
SETTING TRANSPARENCY OF OVERLAY
Overlay transmission rate is set. The default setting is 50%.
1 Tap the of the set item display "Transparency of overlay" of "DIS-
PLAY."
2 Tap the and select one of "0%", "25%", "50% or "75%".
"0%" : No transparency of overlay.
"25%" : Transparency of overlay is set to25%.
"50%" : Transparency of overlay is set to50%.
"75%" : Transparency of overlay is set to75%.
3 Setting is complete.
SETTING THE MARKER OVERLAY
In the Corneal Aberration map and IOL Selection map, display or not display the marker over-
lay is set. Before shipment, the default setting is " OFF."
• This is not applied except the Corneal Aberration map and IOL Selection map.
1 Tap the of the set item display "Marker Overlay" of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE HARTMANN DETECTION POINT OVERLAY (HARTMANN POINT OVERLAY)
When analysis results are initially displayed, Hartmann Detection Point Overlay can be set to
ON or OFF. Before shipment, the default setting is "OFF."
1 Tap the of the set item display "Hartmann Detection Point Overlay"
of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE HARTMANN DETECTION GRID OVERLAY (HARTMANN POINT OVERLAY)
When analysis results are initially displayed, Hartmann Detection Grid Overlay can be set to
ON or OFF. Before shipment, the default setting is "OFF."
1 Tap the of the set item display "Hartmann Detection Grid Overlay"
of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE TOTAL ABERRATION MAP DISPLAY STEP (TOTAL ABERRATION MAP RANGE)
The Total Aberration Map Display Step is set. Before shipment, the default setting is "20 m."
1 Tap the of the set item display "Total Aberration Map Range" of
"DISPLAY."
2 Enter the number by the ten-key display of the .
Set Condition button
Setting Change button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
