Topcon KR-1W - Page 150

148
FUNCTION SETTING USING SETTINGS SCREEN
3 Setting is completed by tapping the .
SETTING THE HIGHER ORDER ABERRATION ASTIGMA MAP OVERLAY - CROSS SCALE
When analysis results are initially displayed, Higher Order Aberration Astigma Map Overlay -
Cross Scale can be set to ON or OFF. Before shipment, the default setting is "ON."
1 Tap the of the set item display "HOA. Astig. Map Overlay - Cross
Scale" of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE HIGH ORDER ABERRATION ASTIGMA MAP OVERLAY - ANGLE SCALE
When analysis results are initially displayed, Higher Order Aberration Astigma Map Overlay -
Angle Scale can be set to ON or OFF. Before shipment, the default setting is "ON."
1 Tap the of the set item display "HOA. Astig. Map Overlay - Angle
Scale" of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE HIGH ORDER ABERRATION ASTIGMA MAP OVERLAY - mm GRID SCALE
When analysis results are initially displayed, Higher Order Aberration Astigma Map Overlay -
mm Grid Scale can be set to ON or OFF. Before shipment, the default setting is "OFF."
1 Tap the of the set item display "HOA. Astig. Map Overlay - mm
Grid Scale" of "DISPLAY."
2 Tap the and select "ON" or "OFF."
3 Setting is complete.
SETTING THE TOPOMAP DISPLAY UNIT (TOPOMAP SCALE UNIT)
The TopoMap display unit is set to "D" or "mm." Before shipment, the default setting is "D."
1 Tap the of the set item display "TopoMap Scale Unit" of "DIS-
PLAY."
2 Tap and select "D" or "mm" of the .
3 Setting is complete.
Display step setting of the Total aberration map can also be done by the Enlarge-
ment Display screen.
For details, see "ENLARGEMENT DISPLAY, Example: Total Aberration" on page
94.
Display step setting of the Total aberration map can also be done by the Enlarge-
ment Display screen.
For details, see "ENLARGEMENT DISPLAY, Example: Total Aberration" on page
94.
OK button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
Set Condition button
Setting Change button
