Topcon KR-1W - Page 151

149
FUNCTION SETTING USING SETTINGS
SETTING THE TOPOMAP SCALE TYPE (TOPOMAP SCALE - TYPE)
The TopoMap scale type may be set to Absolute, Adjustable, or Normalized. Before shipment,
the default setting is "Absolute."
1 Tap the of the set item display "TopoMap Scale - Type" of "DIS-
PLAY."
2 Tap and select "Adjustable," "Normalized" or "Absolute" of the .
"Adjustable" : Relative scale display. Center value or step value can be selected.
"Normalized": Relative scale display. Center value or step value is selected automatically.
"Absolute" : Absolute scale display. The center value is constant, but the step value is
changeable.
3 Setting is complete.
SETTING THE CENTER VALUE WHEN TOPOMAP SCALE TYPE IS ADJUSTABLE
(TOPOMAP SCALE - ADJUSTABLE)
The center value when the TopoMap scale type is Adjustable is set. The value can be set
between 30.00D and 50.00D with 0.50D steps. Before shipment, the default setting is "47.50."
1 Tap the of the set item display "TopoMap Scale - Adjustable" of
"DISPLAY."
2 Enter the number by the ten-key display of the .
3 Setting is completed by tapping the .
SETTING THE STEP WHEN TOPOMAP SCALE TYPE IS ADJUSTABLE
(TOPOMAP SCALE - ADJUSTABLE STEP)
When the TopoMap scale type is set to Adjustable, the step can be set between 0.25D and
2.50D with 0.25D steps. Before shipment, the default setting is "1.50."
1 Tap the of the set item display "TopoMap Scale - Adjustable Step"
of "DISPLAY."
2 Enter the number by the ten-key display of the .
3 Setting is completed by tapping the .
SETTING THE STEP WHEN TOPOMAP SCALE TYPE IS ABSOLUTE
(TOPOMAP SCALE - ABSOLUTE STEP)
When the TopoMap scale type is set to Absolute, the step can be set between 0.50D and
2.50D with 0.25D steps. Before shipment, the default setting is "1.50."
1 Tap the of the set item display "TopoMap Scale - Absolute Step" of
"DISPLAY."
2 Enter the number by the ten-key display of the .
3 Setting is completed by tapping the .
Set Condition button
Setting Change button
Set Condition button
Setting Change button
OK button
Set Condition button
Setting Change butto
n
OK button
Set Condition button
Setting Change butto
n
OK button
