Topcon KR-1W - Page 156

154
FUNCTION SETTING USING SETTINGS SCREEN
1 Tap the of the set item display "Map of analysis screen layout but-
ton 1" of "DISPLAY."
2 Tap the and select the applicable map.
3 Setting is complete.
SETTING THE MAP OF ANALYSIS SCREEN LAYOUT BUTTON 2
The map to be placed in the Layout Change button of the Analysis Result screen can be
selected. Before shipment, the default setting is "Ocular Maps."
1 Tap the of the set item display "Map of analysis screen layout but-
ton 2" of "DISPLAY."
2 Tap the and select the applicable map.
3 Setting is complete.
SETTING THE MAP OF ANALYSIS SCREEN LAYOUT BUTTON 3
The map to be placed in the Layout Change button of the Analysis Result screen can be
selected. Before shipment, the default setting is "Corneal Maps."
1 Tap the of the set item display "Map of analysis screen layout but-
ton 3" of "DISPLAY."
2 Tap the and select the applicable map.
3 Setting is complete.
SETTING THE MAP OF ANALYSIS SCREEN LAYOUT BUTTON 4
The map to be placed in the Layout Change button of the Analysis Result screen can be
selected. Before shipment, the default setting is "Zernike Maps."
1 Tap the of the set item display "Map of analysis screen layout but-
ton 4" of "DISPLAY."
2 Tap the and select the applicable map.
3 Setting is complete.
• For map types and details, see "DESCRIPTION OF MAP LAYOUT" on page 78.
• It is not possible to set custom maps and pupillometry map to custom layout but-
tons.
• For map types and details, see "DESCRIPTION OF MAP LAYOUT" on page 78.
• It is not possible to set custom maps and pupillometry map to custom layout but-
tons.
• For map types and details, see "DESCRIPTION OF MAP LAYOUT" on page 78.
• It is not possible to set custom maps and pupillometry map to custom layout but-
tons.
• For map types and details, see "DESCRIPTION OF MAP LAYOUT" on page 78.
• It is not possible to set custom maps and pupillometry map to custom layout but-
tons.
Set Condition button
Setting Change butto
n
Set Condition button
Setting Change butto
n
Set Condition button
Setting Change butto
n
Set Condition button
Setting Change butto
n
