Toshiba B-FV4 Series User Manual

7. B-FV Setting Tool EO18-33030
7.2 Working with B-FV Setting Tool (V1.0.21)
7-34
8. Click Send to print the output of the command.
Note If you send command files and your printer doesn’t print, it is possible that the
emulation language is not set correctly. Click Sync to get the current setting of Printer
Emulation.
Tool
Tool is used to send specific commands to your printer. It has the Single Command tab, which
provides three commands.
￭ Reboot Printer Restart your printer.
￭ Change Emulation Change the emulation language for your printer.
￭ Media Calibration Change the media sensor for your printer.

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
