1. OUTLINE EO18-33030
1.1 Feature of the B-FV4 series
1-6
B-FV4D-GS/TS
B-FV4D-GH
Print Head
Feed Gap Sensor
Core Holders
Media Roll Holders
Holder Lock Lever
Media Guides
Black Mark Sensor
Platen Roller
Thumbscrew
Media Roll Holders
Lock Release Portions
Media Roll Holder Lever
Thumbscrew
Peel-off Unit
Platen Roller
Print Head
Media Sensor
Peel-off Sensor
Media Guide
Media Guide
