2. ELECTRONICS SPECIFICATIONS EO18-33030
2.3 Main PC Board Connector Pin Assignment
2-10
JP2 (Parallel Interface port): This connector is used for the Parallel interface (Centronics).
Signal
Pin
No.
n/STROBE 1
Data 1-8 2-9
nACK 10
BUSY 11
PE 12
5V 13
NC 14
NC 15
Ground 16
Ground 17
NC 18
Ground 19-30
NC 31
nFAULT 32
NC 33-35
NC 36

Toshiba B-FV4 Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5 – 40 °C
Storage Temperature	-20 – 60 °C
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB, Serial (RS-232)
Media Width	25.4 – 112 mm
