290
The following entries are displayed on this screen:

Graphic Show
Collect Topology: Click the Collect Topology button to display the cluster topology.
Manage:
If the current device is the commander switch in the cluster and
the selected device is a member switch in the cluster, you can
click the Manage
button to log on to Web management page of
the corresponding switch.
Global configuration procedure of the Cluster function:
Before configuring a cluster, you should make clear the role each device will play in the cluster in
advance and make sure the devices in the cluster can communicate with each other.
 If the switch is a commander switch in the cluster, please take the following steps.
Step Operation Description
1 Enable the NDP function globally
and for the port, and then
configure NDP parameters
Optional. On Cluster→NDP→NDP Config page,
enable the NDP function on the switch.
2 Enable the NTDP function globally
and for the port, and then
configure NTDP parameters
Optional. On Cluster→NTDP→NTDP Config page,
enable the NTDP function on the switch.
3 Establish a cluster and configure
the related parameters
Optional. On Cluster→Cluster→
Cluster Config
page, e
stablish a cluster and configure the related
parameters.
4 Manage the device in the cluster Optional. On Cluster→Cluster→
Member Config
page, select the desired member switches and click
the Manage button to log on to its Web management
page for configuration.
Or
On Cluster→Cluster→Cluster Topology page,
double- click the icon of the switch to view its detailed
information; click the icon, and then click the Manage
button to log on to its Web management page for
configuration.
 If the switch is a member switch in the cluster, please take the following steps.
Step Operation Description
1 Enable the NDP function globally
and for the port, and then
configure NDP parameters
Optional. On Cluster→NDP→NDP Config page,
enable the NDP function on the switch.
2 Enable the NTDP function globally
and for the port, and then
configure NTDP parameters
Optional. On Cluster→NTDP→NTDP Config page,
enable the NTDP function on the switch.
