Setup Menu
SETUP MENU See: Description
1=SETUP INPUT Setup Inputs Configure digital inputs
2=SETUP COMMON ALARM
Setup Common
Alarm
Set upthe common alarm to reset with silence
3=SETUP SENSOR Setup Sensor Configure analog inputs
4=SETUP ZONES Setup Zones Assign devices to separate areas
5=SETUP OUTPUTS Setup Output Configure digital outputs
6=SETUP MODEM&PAGERS
Setup Modem &
Pagers
Configure modem and up to four pager numbers
7=SETUP SYSTEM INFORMATION* Setup System Info Set up features such as password and date & time*
8=SETUP OPERATION Setup Operation Specify rotation sequence, standby testing, staging
9=OVERRIDE OUTPUT Override Output Manually override automatic control of outputs
0=CLEAR ALARMS&LOGS Clear Alarms & Logs Clear active alarms; clear alarm, event & trend logs
A=SETUP I/O MATRIX Setup I/O Matrix Specify inputs to trigger actions in control relays
I=RETURN TO MAIN MENU
SELECT A NUMBER:
* Setup System Information features are:
• Change Password
• Set Date & Time/Automatic Daylight Saving Time
• Setup Site ID
• Connect Battery
• Backup and Upload Configuration File (Service Terminal Interface only)
• Setup Service Phone Number
• Factory Defaults
• Firmware Update (Service Terminal Interface only)
• Initiate Remote Alarm Test (Service Terminal Interface only)
Note that three of these system features—Backup and Upload Configuration File, Firmware
Update and Initiate Remote Alarm Test—are unique to the Service Terminal Interface.
Tips on Using the Service Terminal Interface
Use the following tips when making changes in the Service Terminal Interface:
• Data that can be entered is shown in parentheses ( ) in prompt line.
• The current setting is shown in brackets [ ] in the line below the prompt
• To accept the current setting, press the Enter key.
• To change the current setting, enter the value and then press Enter.
• Pressing Escape will exit the current setup function or take you to the previous menu screen.
