Operation0530−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
CYL. LUB.
OIL
PRESS.
CYL. LUB.
VALVE
COMMAND 1
PT
313YC
CV
713YC
CYL. LUB.
OIL
PRESS.
CYL. LUB.
VALVE
COMMAND 1
PT
313YC
CV
713YC
CYL. LUB.
OIL
PRESS.
CYL. LUB.
VALVE
COMMAND 1
PT CV
CYL. LUB.
OIL
PRESS.
CYL. LUB.
VALVE
COMMAND 1
PT
313XC
713XC
Defective CCM−20
CCM−20
Attached to CYL. Y
CCM−20
Attached to CYL. X
Serviceable CCM−20
CYLINDER Y
A
BC
Socket A
Socket B
Socket C
Usual Cylinder Lubrication
CYLINDER X
Emergency Cylinder Lubrication
Terminal Box
(Tool 94929)
WCH01087
Terminal Box
(Tool 94929)
Fig. 2: Schematic Diagram − Emergency Lubrication
2015-03
CCM−20 Failure
