Operation
2138−1/A1
Winterthur Gas & Diesel Ltd.
1/ 2
Lubricating Quills on Cylinder Liner
1. General
Eight lubricating quills (1, Fig. 1) are are installed around the circumference of the
cylinder liner (2). The lubricating pump (4) installed on the rail unit, supplies
lubricating oil through pipes to each lubricating quill.
WCH02268
1
4
2
3
FREE END
Fig. 1: Location of Lubricating Quills
1 Lubricating quill 3 Cylinder block
2 Cylinder liner 4 Lubricating pump 25_7206_C#_1
2014
