Operation9223−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
I
DRIVING END
WCH02520
8
9
11
10
I
8
WCH02522
10 11
8
1
11
WCH02523
2 to 5
9
Fig. 6: Crank angle sensor unit
1 Intermediate wheel 8 Flywheel
2 Proximity sensor ST5131C 9 Crank angle mark
3 Proximity sensor ST5132C 10 Proximity sensor ZS5123C
4 Proximity sensor ST5133C 11 Proximity sensor ZS5124C
5 Proximity sensor ST5134C
Crank Angle Sensor Unit
2014
