January 2010
2-358
Phaser 7760 Color Laser Printer
024-946, 024-947
Revised
Status Indicator RAP’s
024-946 Tray 2 Out of Place
Tray 2 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 2 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 2 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 2 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Go to RAP 007-270, Tray 2 Paper Size Sensor.
024-947 Tray 3 Out of Place
Tray 3 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 3 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 3 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 3 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Go to RAP 007-271, Tray 3 Paper Size Sensor.
To Next Page
