January 2010
2-359
Phaser 7760 Color Laser Printer
024-948, 024-949
Status Indicator RAP’s
Revised
024-948 Tray 4 Out of Place
Tray 4 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 4 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 4 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 4 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to the Service Call Procedures.
The machine is equipped with a 3TM.
YN
Go to RAP 007-276, Tray 4 Paper Size Sensor (TTM).
Go to RAP 007-272, Tray 4 Paper Size Sensor (3TM).
024-949 Tray 5 Out of Place
Tray 5 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 5 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 5 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 5 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to the Service Call Procedures.
The machine is equipped with a 3TM.
YN
Go to RAP 007-277, Tray 5 Paper Size Sensor (TTM).
Go to RAP 007-273, Tray 5 Paper Size Sensor (3TM).
To Next Page
