Xerox Phaser 7760 Service Manual

January 2010
2-21
Phaser 7760 Color Laser Printer
003-947, 003-948
Status Indicator RAP’s
Revised
003-947 Tray 3 Out of Place
Tray 3 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 3 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 3 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 3 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Go to RAP 007-271, Tray 3 Paper Size Sensor.
003-948 Tray 4 Out of Place
Tray 4 not in position.
Initial Actions
• Check that the paper size setting is correct.
• Check the Tray 4 Paper Size Sensor for damage or incorrect mounting. Repair or replace
as required.
• Check the Switch Actuators on Tray 4 for wear or damage. Repair or replace as required.
Procedure
Ensure Tray 4 is closed. Turn the printer power Off, then On. The problem continues.
YN
Return to the Service Call Procedures.
The machine is equipped with a 3TM.
YN
Go to RAP 007-276, Tray 4 Paper Size Sensor (TTM).
Go to RAP 007-272, Tray 4 Paper Size Sensor (3TM).
