Xerox WorkCentre 5024 Service Manual

06/2014
7-4
WC 5022/5024
7.1.1 Plug/Jack Location List
Version 1.0
Wiring Data
P/J205 7 7 Tray 1 Feed Clutch
P/J206 4 4 MSI Feed Clutch
P/J207 11 13 ESS/MCU PWB (to Toner Dispense Motor)
P/J208 7 2 Invert Motor
P/J209 11 7 ESS/MCU PWB (to Nohad Fan)
P/J220A 12 1 Tray 4 Feed/Lift Up Motor (2TM)
P/J220B 12 1 Tray 3 Feed/Lift Up Motor (2TM)
P/J220C 9 1 Tray 2 Feed/Lift Up Motor (1TM)
J352 14 3 Connector (Connect to P5)
P353 14 4 Connector (Connect to J2)
P/J400 11 16 ESS/MCU PWB
P/J401 11 14 ESS/MCU PWB
P/J402 11 12 ESS/MCU PWB
P/J403 11 9 ESS/MCU PWB
P/J405 11 8 ESS/MCU PWB
P/J406 11 11 ESS/MCU PWB
P/J407 11 10 ESS/MCU PWB
P/J409 11 15 ESS/MCU PWB
P/J410 11 18 ESS/MCU PWB
P/J411 11 19 ESS/MCU PWB
P/J412 11 17 ESS/MCU PWB
P413 11 21 ESS/MCU PWB (Connect to J413)
J413 9 8 Connector (Connect to P413)(1TM)
P413C 10 8 STM PWB (Connect to J413C)(1TM)
J413C 12 12 Connector (Connect to P413C)(2TM)
P/J414 11 20 ESS/MCU PWB
P/J415 11 1 ESS/MCU PWB
P/J420 11 4 ESS/MCU PWB
P421 11 5 ESS/MCU PWB (Connect to J421)
J421 2 18 Connector (Connect to P421)
P/J422 11 3 ESS/MCU PWB
P425 11 25 ESS/MCU PWB (Connect to J425)
J425 14 2 NET I/F PWB (Connect to P425)
P441 11 22 ESS/MCU PWB (Connect to J441)
J441 14 9 Connector (Connect to P441)
P442 14 10 Connector (Connect to J442)
J442 11 23 ESS/MCU PWB (Connect to P442)
J443 11 24 ESS/MCU PWB
J444 14 1 NET I/F PWB
P/J445 11 2 ESS/MCU PWB
P/J500 7 1 HVPS
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)
P/J510 8 6 LVPS
P/J511 8 5 LVPS
P/J512 8 4 LVPS
P/J513 8 3 LVPS
P/J541 13 2 2TM PWB
P/J541C 10 1 STM PWB
P/J548 13 1 2TM PWB
P/J548C 10 6 STM PWB
P/J549 13 7 2TM PWB
P/J549C 10 5 STM PWB
P/J552 13 8 2TM PWB
P/J552C 10 7 STM PWB
P/J554 13 3 2TM PWB
P/J600 4 9 Fusing Unit (4pin)
P/J601 4 5 Connector (5pin)
P/J602 4 8 Connector (3pin)
P/J615 5 8 ATC Sensor
P/J620 5 4 Connector
P/J661A 12 8 Connector (2TM)
P/J661B 12 9 Connector (2TM)
P/J661C 9 5 Connector (1TM)
P/J700 3 7 CCD PWB
P/J721 3 2 Carriage Motor
P/J722 3 1 IIT Regi. Sensor
P/J723 3 13 Platen Open Sensor
P/J725 3 12 Platen Angle Sensor
P/J726 3 14 APS Sensor 1
P/J740 3 11 UI PWB
P/J751 2 9 DADF PWB
P/J752 2 8 DADF PWB
P/J753 2 7 DADF PWB
P/J754 2 4 DADF PWB
P/J756 2 5 DADF PWB (to Exit Nip Release Solenoid)
P/J758 2 6 DADF PWB
P/J759 2 3 DADF PWB
P/J760 2 2 DADF PWB
P/J761 2 1 DADF PWB
P762 2 11 DADF PWB
P763 2 10 DADF PWB
P/J764 1 3 Document Tray Size Sensor 1
P/J765 1 4 Document Tray Size Sensor 2
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
