7.1 Connecting the Digital Operator
There are two types of Digital Operator. One is a built-in operator incorporating a panel indica-
tor and switches located on the front panel of the SERVOPACK. This type of Digital Operator is
also called a Panel Operator. The other one is a Hand-held Digital Operator (i.e., the JUSP-
OP02A-2 Digital Operator), which can be connected to the SERVOPACK through connector
CN3 of the SERVOPACK.
There is no need to turn OFF the SERVOPACK to connect the Hand-held Digital Operator to
the SERVOPACK. For details on how to use the Hand-held Digital Operator, refer to the Σ-
ΙΙ
Series SGMH/SGDH User’s Manual (SIEPS80000005).
