4.3 Main Commands
4-17
4
4.3.10 Disconnection (DISCONNECT: 0FH)
Byte DISCONNECT Description
Command Response
1 0FH 0FH Processing
classifications
Network com-
mand group
Synchronization
classifications
Asynchronous
2 ALARM Processing time Communications
cycle or more
Subcommand Cannot be used.
3STATUS• Releases the MECHATROLINK-II connection. The SERVOPACK changes
communication to phase 1.
• Can be used during any phase.
• When this command is received, the following operations will be performed.
- The SERVOPACK changes communication to phase 1.
- The SERVOPACK changes to Servo OFF.
- The reference point setting will become invalid.
4
5
6
7
8
9
10
11
12
13
14
15
16 WDT RWDT
