7 Digital Operator
7-4
7.3 Panel Operator Indicators
The Panel Operator indicator (LED) will not be lit in any of the following circumstances.
• The indicator will not be lit for approximately 3 seconds when the power is turned ON.
• The indicator will not be lit when the Hand-held Digital Operator is connected.
It will be lit when the Hand-held Digital Operator is disconnected.
• The indicator will not be lit for approximately 1 second when the following commands
are received.
- PRM_RD command
- PRM_WR/PPRM_WR command
- CONFIG command
- SENS_ON command
- ADJ command
- ALM_RD/ALM_CLR command for the error history
- Reading ID_RD command model
