1 Checking Products and Part Names
1-4
1.2 Product Part Names
The following diagram illustrates the product part names of the NS115.
Fig. 1.3 NS115
RotarySwitch(SW1):UsedtosettheMECHATROLINK-IIstationaddress.
LEDA:Litwhenanalarmoccurs.
LEDR:LitwhenMECHATROLINK-IIcommunicationsareinprogress.
DIPSwitch(SW2):UsedtosetMECHATROLINK-IIcommunications.
Nameplate:Indicatesthemodelandserialnumbers.
MECHATROLINK-IICommunicationsCN6AandCN6BConnectors:
ConnectstotheMECHATROLINK-IIsystem.
CN4FullyClosedEncoderSignalConnector:Usedforfullyclosed
signalconnection.
A
R
NS115
S
W
1
S
W
2
C
N
6
A
C
N
6
B
C
N
4
Groundwire:Connecttotheterminalmarked"G"ontheSGDHSERVOPACK.
