8 Ratings, Specifications, and Dimensional Drawings
8.2.2 SERVOPACKs
8-4
8.2.2 SERVOPACKs
Dimensional drawings of the Base-mounted Standard SERVOPACKs (with NS115
mounted) are shown below. For detailed dimensional drawings, refer to Σ-
ΙΙ
Series
SGM
H/SGDH User’s Manual (SIEPS80000005).
For details of the Rack-mounted and Duct-ventilated SERVOPACKs, refer also to Σ-
ΙΙ
Series SGM
H/SGDH User’s Manual (SIEPS80000005).
Base-Mounted Models
SGDH-A3AE to -02AE (Single-phase, 200 V, 30 to 200 W)
SGDH-A3AE to -01BE (Single-phase, 100 V, 30 to 100 W)
SGDH-04AE (Single-phase, 200 V, 400 W)
SGDH-02BE (Single-phase, 100 V, 200 W)
Unit: mm (in)
MADE IN JAPAN
NS115
S
W
1
A
R
S
W
2
C
N
6
A
C
N
6
B
C
N
4
Ver.
160 (6.30)
75 (2.95)
(75 (2.95) ) 130 (5.12)
Approx. mass: 1.0 kg (2.21 lb)
160 (6.30)
95 (3.74)
(75 (2.95) ) 130 (5.12)
MADE IN JAPAN
NS115
S
W
1
A
R
S
W
2
C
N
6
A
C
N
6
B
C
N
4
Ver.
Approx. mass: 1.3 kg (2.87 lb)
