Notation Used in this Manual
Notation for Reverse Signals
The names of reverse signals (i.e., ones that are valid when low) are written with a forward slash (/)
before the signal abbreviation.
Notation Example
BK
is written as /BK.
Notation for Parameters
The notation depends on whether the parameter requires a numeric setting (parameter for numeric
setting) or requires the selection of a function (parameter for selecting functions).
•
Parameters for Numeric Settings
Notation Example
Engineering Tools Used in This Manual
This manual uses the interfaces of the SigmaWin+ for descriptions.
This is the setting range
for the parameter.
Parameter
number
This column explains the
selections for the function.
This is the
parameter setting
before shipment.
This is when any
change made to the
parameter will
become effective.
This is the parameter
classication.
This is the minimum
unit (setting increment)
that you can set for
the parameter.
Parameter Meaning When Enabled Classication
Pn002
n.
0
After restart Setup
n.1
n.2
Parameter
number
Pn100
Speed Loop Gain
Setting Range
10 to 20,000 0.1 Hz 400 Immediately
Setting Unit Default Setting When Enabled
Classication
Tuning
(default setting)
Use the encoder according to encoder specications.
Use the encoder as an incremental encoder.
Use the encoder as a single-turn absolute encoder.
The notation “n.” indicates a parameter for selecting functions.
Each indicates the setting for one digit.
The notation shown here means that the third digit from the right is set to 2.
The following format is used to show the individual bits of a parameter
setting: b. .
The individual bits of a parameter setting have specific meanings, but you
cannot set the bits individually. The individual bits must be converted to a
hexadecimal value to set a parameter.
Refer to the following section for details on settings.
•
Parameters for Selecting Functions
15.1.2 List of Parameters (page 15-3)
Notation Examples for Pn002
Pn002 =
n.
X
Indicates the rst digit from
the right in Pn002.
Pn002 =
n.
1
Indicates that the rst digit from
the right in Pn002 is set to 1.
Pn002 =
n.
X
Indicates the second digit
from the right in Pn002.
Pn002 =
n.
1
Indicates that the second digit from
the right in Pn002 is set to 1.
Pn002 =
n.
X
Indicates the third digit from
the right in Pn002.
Pn002 =
n.
1
Indicates that the third digit from
the right in Pn002 is set to 1.
Pn002 =
n.X
Indicates the fourth digit from
the right in Pn002.
Pn002 =
n.1
Indicates that the fourth digit from
the right in Pn002 is set to 1.
n.0 0 0 0
Notation
Digit Notation Numeric Value Notation
Meaning Notation Meaning
To Next Page
