YASKAWA SGDV-OCA05A

13.1 DeviceNet Communications Settings
13.1.2 Setting the Baud Rate
13-4
13.1.2 Setting the Baud Rate
Use the DR rotary switch on the front panel of the DeviceNet Module to set the DeviceNet baud
rate.
Rotary Switch
Setting (DR)
Baud Rate Setting
0 125 kbps
1 250 kbps
2 500 kbps
3 to 9 Setting error
To enable the new setting, turn the power supply to the SERVOPACK OFF and ON again after
you change the setting.
Rotary switch (DR)
DeviceNet
Module
Important
