This chapter describes the basic functions that must be set
before you start servo system operation. It also describes
the setting methods.
5.1
Manipulating Parameters (Pn) . . . . . . 5-3
5.1.1 Parameter Classification . . . . . . . . . . . . . . . . . . . 5-3
5.1.2 Notation for Parameters . . . . . . . . . . . . . . . . . . . 5-4
5.1.3 Parameter Setting Methods . . . . . . . . . . . . . . . . 5-5
5.1.4 Write Prohibition Setting for Parameters . . . . . . . 5-8
5.1.5 Initializing Parameter Settings . . . . . . . . . . . . . . 5-10
5.1.6 Managing Parameters (Pn) . . . . . . . . . . . . 5-12
5.2
Power Supply Type Settings for the Main Circuit and Control Circuit . . . 5-13
5.2.1 AC Power Supply Input/DC Power Supply
Input Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.2.2 Single-phase AC Power Supply Input/
Three-phase AC Power Supply Input Setting . . 5-14
5.3
Automatic Detection of Connected Motor . . 5-15
5.4
Motor Direction Setting . . . . . . . . . . . . . . . 5-16
5.5
Setting the Linear Encoder Pitch . . . . . . . 5-17
5.6
Writing Linear Servomotor Parameters . . . 5-18
5.7
Selecting the Phase Sequence for a Linear Servomotor . . 5-22
5.8
Polarity Sensor Setting . . . . . . . . . . . . . . . 5-24
Basic Functions That
Require Setting
before Operation
5
To Next Page
