2.1 Ratings and Specifications
2.1.2 DeviceNet Module Power Loss
2
Selecting a SERVOPACK
2-5
2.1.2 DeviceNet Module Power Loss
The power supply method and power loss of a DeviceNet Module depend on the model of the
DeviceNet Module.
SGDV-OCA04A (Interface: Driven by Control Power Supply)
The specifications of the SGDV-OCA04A DeviceNet Module are given in the following table.
SGDV-OCA05A (Interface: Driven by External Power Supply)
The specifications of the SGDV-OCA05A DeviceNet Module are given in the following table.
Item
Specification
DeviceNet Communications Section Control Section
Power Supply Method
Supplied from the DeviceNet
communications cable.
Supplied from the control power supply
of a Command Option Attachable-Type
SERVOPACK.
Minimum Operating
Voltage
11 VDC
Included in the current consumption of
the Command Option Attachable-Type
SERVOPACK.
Maximum Operating
Voltage
25 VDC
Maximum Operating
Current
25 mA
Maximum Power Loss 625 mW
Item
Specification
DeviceNet Communications Section Control Section
Power Supply Method Supplied from the DeviceNet communications cable.
Minimum Operating
Voltage
11 VDC
Maximum Operating
Voltage
25 VDC
Maximum Operating
Current
100 mA for 24-VDC power supply
200 mA for 11-VDC power supply
Maximum Power Loss 2.4 W
