5.16 Setting the Origin of the Absolute Encoder
5.16.1 Absolute Encoder Origin Offset
5-49
5
Basic Functions That Require Setting before Operation
5.16
Setting the Origin of the Absolute Encoder
5.16.1
Absolute Encoder Origin Offset
Refer to the following section for details.
Origin Offset on page 12-4
5.16.2
Setting the Origin of the Absolute Linear Encoder
You can set any position as the origin in the following Linear Encoders.
• Mitutoyo Corporation
ABS ST780A Series or ST1300 Series
Models: ABS ST78A/ST78AL/ST13
• Renishaw PLC
EVOLUTE Series
Models: EL36Y-
• Renishaw PLC
RESOLUTE Series
Models: RL36Y-
Preparations
Always check the following before you set the origin of an absolute encoder.
• The parameters must not be write prohibited.
• The servo must be OFF.
Applicable Tools
The following table lists the tools that you can use to set the origin of the absolute linear
encoder and the applicable tool functions.
1. After you set the origin, the /S-RDY (Servo Ready) signal will become inactive because the
system position data was changed. Always turn the SERVOPACK power supply OFF and ON
again.
2. After you set the origin, the Servomotor phase data in the SERVOPACK will be discarded. If
you are using a Linear Servomotor without a Polarity Sensor, execute polarity detection again
to save the Servomotor phase data in the SERVOPACK.
Tool Function Reference
Digital Operator Fn020
Σ-7-Series Digital Operator Operating
Manual (Manual No.: SIEP S800001
33)
SigmaWin+ Setup - Set Origin
Operating Procedure on page 5-50
Important
To Next Page
