13.5 Reading and Changing Attributes
13.5.3 Executing a Module Reset
13
DeviceNet Communications
13-33
13.5.3
Executing a Module Reset
You can use an explicit message to reset the SERVOPACK by executing the Reset service for
the Identity object. The following example is for a master device with a MAC ID of 0.
Commands (Master Device to SERVOPACK)
When the Module is reset, the same processing as when the power supply is turned ON will be
performed by the SERVOPACK. This means that DeviceNet communications will be inter-
rupted.
If the Master device does not support automatic recovery of DeviceNet communications, it will
be necessary to reconnect DeviceNet communications.
The following operations will be performed when the Module is reset.
• All parameters are stored in non-volatile memory.
• The parameters that require turning the power supply OFF and ON again are enabled.
7 6 5 4 3 2 1 0
00 0
00x05
0x01 (Identity object)
0x01 (Instance: 1)
To Next Page
