4.7 DeviceNet System Configuration
4.7.1 System Configuration Example for DeviceNet Communications
4-40
4.7
DeviceNet System Configuration
4.7.1
System Configuration Example for
DeviceNet Communications
A system configuration example for DeviceNet communications is provided below.
A maximum of 63 slave devices, such as SERVOPACKs, can be connected to one host con-
troller (DeviceNet master).
SERVOPACK AC driveSERVOPACK
I/O signal device from another manufacturer
DeviceNet: 63 nodes max.
DeviceNet Master Module
MP3000-Series Machine Controller
