Administrator
’
s Guide for SIP-T5
Series Smart Media Phones
84
3.
Select
Enabled
from the pull-down list of
NAT
.
4.
Click
Confirm
to accept the change.
To configure local SIP port and TLS SIP port via web user interface:
1.
Click on
Settings
->
SIP
.
2.
Enter the desired local SIP port in the
Local SIP Port
field.
105
107
Table of Contents
Default Chapter
2
Declaration of Conformity
2
Class B Digital Device or Peripheral
3
Gnu Gpl Information
4
Introduction
5
About this Guide
5
Chapters in this Guide
5
Conventions Used in Yealink Documentations
7
Reading the Configuration Parameter Tables
7
Summary Table Format
8
Configuration Parameter Table Format
9
Recommended References
11
Understanding Voip Principle and SIP Components
11
Voip Principle
12
SIP Components
13
Table of Contents
15
Table of Contents
17
Product Overview
23
SIP IP Phone Models
23
Physical Features of IP Phones
24
Key Features of IP Phones
26
Expansion Modules
27
Getting Started
29
What IP Phones Need to Meet
29
Yealink IP Phones in a Network
29
Connecting the IP Phones
30
Inserting the Camera (Not Applicable to SIP-T56A IP Phones)
31
Attaching the Stand and the Optional Wall Mount Bracket
32
Adjust the Angle of Touch Screen (Not Applicable to SIP-T56A IP Phones)
34
Connecting the Handset and Optional Headset
34
Connecting the Power and Network
35
Connecting the Optional USB Flash Drive
37
Initialization Process Overview
38
Verifying Startup
39
Setting up Your System
41
Setting up Your Phone Network
41
Dhcp
42
DHCP Option
46
Configuring Network Parameters Manually
50
Pppoe
56
Configuring Transmission Methods of the Internet Port and PC Port
58
Configuring PC Port Mode
62
Web Server Type
64
Wi-Fi
68
Vlan
70
Ipv6 Support
83
Vpn
92
Configuring the IP Phone for Use with a Firewall or NAT
96
Nat Traversal
100
Quality of Service (Qos)
111
Voice Qos
112
802.1X Authentication
115
Setting up Your Phones with a Provisioning Server
127
Provisioning Points to Consider
127
Provisioning Methods
128
Phone User Interface
130
Boot Files, Configuration Files and Resource Files
131
Configuration Files
133
Resource Files
135
Setting up a Provisioning Server
138
Supported Provisioning Protocols
139
Deploying Phones from the Provisioning Server
140
Upgrading Firmware
141
Keeping User Personalized Settings after Auto Provisioning
149
Configuring Basic Features
161
Power Indicator LED
163
Notification Popups
167
Wallpaper
170
Screen Saver
174
Power Saving
174
Backlight
179
Bluetooth
181
Enable Page Tips
184
Page Tips for Expansion Module
186
Account Registration
187
Multiple Line Keys Per Account
194
Call Display
198
Display Method on Dialing
200
Time and Date
202
NTP Time Server
203
Time and Date Settings
208
Daylight Saving Time (DST)
211
Language
219
Loading Language Packs
220
Specifying the Language to Use
227
Softkey Layout
229
Customizing Softkey Layout Template File
231
Key as Send
236
Dial Plan
241
Dial Plan Using XML Template Files
241
Replace Rule
242
Area Code
251
Block out
254
Dial Plan Using Digit Map String Rules
256
Emergency Dialplan
265
Hotline
269
Off Hook Hot Line Dialing
272
Search Source List in Dialing
273
Customizing a Super Search Template File
274
Save Call Log
276
Call List Show Number
278
Missed Call Log
280
Local Directory
281
Customizing a Local Contact File
282
Configuring Local Directory
290
Live Dialpad
296
Speed Dial
298
Call Waiting
302
Auto Redial
306
Auto Answer
308
IP Direct Auto Answer
312
Allow IP Call
314
Accept SIP Trust Server Only
315
Call Completion
317
Anonymous Call
320
Anonymous Call Rejection
324
Do Not Disturb (DND)
327
Busy Tone Delay
339
Return Code When Refuse
341
Early Media
343
180 Ring Workaround
343
Use Outbound Proxy in Dialog
344
SIP Session Timer
346
Session Timer
348
Call Hold
351
Music on Hold (Moh)
354
Call Forward
357
Call Transfer
376
Local Conference
379
Network Conference
380
Transfer on Conference Hang up
382
Feature Key Synchronization
383
Transfer Mode Via Dsskey
385
Directed Call Pickup
386
Group Call Pickup
395
Dialog Info Call Pickup
402
Recent Call in Dialing
405
Recall
407
Call Number Filter
409
Call Park
411
Calling Line Identification Presentation (CLIP)
415
Connected Line Identification Presentation (COLP)
419
Mute
422
Allow Mute
422
Keep Mute
423
Intercom
424
Outgoing Intercom Calls
425
Intercom Key
426
Incoming Intercom Calls
430
Call Timeout
433
Ringing Timeout
434
Send User=Phone
434
SIP Send MAC
436
SIP Send Line
438
Reserve # in User Name
440
Password Dial
442
Unregister When Reboot
444
100 Reliable Retransmission
445
Reboot in Talking
447
Answer by Hand
449
Call Recording Using Soft Key
450
Silent Mode
451
Door Phone
452
Mobile Account
455
Quick Login
459
Configuring Advanced Features
461
Remote Phone Book
461
Customizing Remote Phone Book Template File
461
Lightweight Directory Access Protocol (LDAP)
469
Busy Lamp Field (BLF)
481
Blf Led Mode
482
Busy Lamp Field (BLF) List
493
Hide Feature Access Codes
499
Shared Call Appearance (SCA)
501
Message Waiting Indicator (MWI)
510
Multicast Paging
515
Sending RTP Stream
515
Receiving RTP Stream
525
Call Recording Using DSS Keys (Record and URL Record)
530
Url Record
531
Hot Desking
537
Logon Wizard
542
Action URL
545
Action URI
565
Configuring Trusted IP Address for Action URI
568
Scenario a - Capturing the Current Screen of the Phone
571
Scenario B - Placing a Call Via Web User Interface
573
Server Redundancy
573
Phone Registration
575
Server Domain Name Resolution
585
Static DNS Cache
588
TR-069 Device Management
596
Configuring Audio Features
603
Redial Tone
603
Ring Tones
604
Distinctive Ring Tones
609
Tones
616
Voice Mail Tone
623
Ringer Device for Headset
624
Headset Prior
626
Dual Headset
628
Sending Volume
629
Audio Codecs
631
Supported Audio Codecs
632
Packetization Time (Ptime)
640
Opus Sample Rate
642
Acoustic Clarity Technology
644
Acoustic Echo Cancellation (AEC)
644
Background Noise Suppression (BNS)
645
Automatic Gain Control (AGC)
645
Voice Activity Detection (VAD)
645
Comfort Noise Generation (CNG)
647
Jitter Buffer
648
Dtmf
652
Methods of Transmitting DTMF Digit
653
Suppress DTMF Display
657
Transfer Via DTMF
659
Play Local DTMF Tone
661
Voice Quality Monitoring (VQM)
662
Rtcp-Xr
663
Vq-Rtcpxr
664
Configuring Video Features
683
Video Settings
683
Video Codecs
685
Configuring Security Features
689
User and Administrator Passwords
689
Auto-Logout Time
691
Phone Lock
692
Transport Layer Security (TLS)
698
Secure Real-Time Transport Protocol (SRTP)
709
Encrypting and Decrypting Files
713
Configuration Parameters
713
Encrypting and Decrypting Configuration Files
717
Procedure to Encrypt Configuration Files
718
Troubleshooting
721
Troubleshooting Methods
721
Viewing Log Files
721
Capturing Packets
735
Enabling Watch Dog Feature
740
Getting Information from Status Indicators
741
Getting Information from Talk Statistics
742
Analyzing Configuration Files
742
Troubleshooting Solutions
746
IP Address Issues
747
Time and Date Issues
748
Display Issues
748
Phone Book Issues
748
Audio Issues
749
Camera and Video Issues
749
Wi-Fi and Bluetooth Issues
750
Firmware and Upgrading Issues
751
Provisioning Issues
752
System Log Issues
752
Resetting Issues
752
Rebooting Issues
757
Protocols and Ports Issues
760
Password Issues
762
Power and Startup Issues
762
Hardware Issues
762
Other Issues
763
Appendix
767
Appendix A: Glossary
767
Appendix B: Time Zones
769
Appendix C: Trusted Certificates
770
Appendix D: Configuring DSS Keys
772
Appendix F: Static Settings
784
Appendix G: Reading Icons
790
Appendix H: SIP (Session Initiation Protocol)
795
RFC and Internet Draft Support
795
SIP Request
798
SIP Header
799
SIP Responses
800
SIP Session Description Protocol (SDP) Usage
803
Appendix I: SIP Call Flows
803
Successful Call Setup and Disconnect
804
Unsuccessful Call Setup-Called User Is Busy
806
Unsuccessful Call Setup-Called User Does Not Answer
808
Successful Call Setup and Call Hold
810
Successful Call Setup and Call Waiting
813
Call Transfer Without Consultation
817
Call Transfer with Consultation
821
Always Call Forward
826
Busy Call Forward
828
No Answer Call Forward
831
Call Conference
834
Index
839
