R Series Service Manual

9650-0903-01 Rev. L 1-13

Test Setup for Off Current Test:

1. Remove 0.1

 resistor and replace with 1K.

2. Connect DMM across resistor.

3. Set voltage scale to DCV.

4. Measure voltage across resistor.

Charger Test

Tools Needed: 2-Post Battery Fixture (9100-0575-TF), DVM, 2 Test Leads, Impulse 4000, Stopwatch.

Test Setup:

Set DVM to read DC Volts.

Connect Postive lead to positive post of the R Series charger load fixture.

Connect negative lead to negative post of the R Series charger load fixture.

Verify the unit is plugged into AC Power.

Do this... Observe this... Pass/Fail

4.10 Off Current Test

Measure across resistor with unit turned off.

Voltage should be less than 270 mV (<270 A of current).

Record your results on the Maintenance Test Checklist.

Do this... Observe this... Pass/Fail

4.11 Set front panel switch to DEFIB or ON, (for BLS

units, press MANUAL MODE, then press

CONFIRM).

4.12 Install Charger Test Fixture.
