226 CHAPTER 11: CONFIGURING SPANNING TREE
■ Port State — Displays the current STP state of a port. If enabled, the
port state determines what forwarding action is taken on traffic.
Possible port states are:
■ Forwarding — Indicates that the port forwards traffic while
learning MAC addresses.
■ Speed — Indicates the speed at which the port is operating.
■ Default Path Cost — Indicates that default path cost is enabled.
■ Path Cost — Indicates the port contribution to the root path cost. The
path cost is adjusted to a higher or lower value, and is used to forward
traffic when a path is re-routed. The field range is 1-200,000,000
.
■ Priority — Priority value of the port. The priority value influences the
port choice when a bridge has two ports connected in a loop. The
priority value is between 0 -240. The priority value is determined in
increments of 16.
■ Designated Bridge ID — Indicates the bridge priority and the MAC
Address of the designated bridge.
■ Designated Port ID — Indicates the selected port priority and
interface.
■ Designated Cost — Indicates the cost of the port participating in the
STP topology. Ports with a lower cost are less likely to be blocked if
STP detects loops.
2 Define the fields.
3 Click . Classic STP is modified on the interface, and the device is
updated.
