Viewing Wireless Settings 37
■ Light Gray — Port has been set to inactive by User or
Protocol.
■ Dark Blue — Port has been selected by user.
■ Red — Port or Transceiver has failed POST or Transceivers not
recognized.
Viewing Wireless
Settings
The Wireless Page displays information regarding the currently configured
access points including IP Address, MAC address, the type and radio
configuration and the current access point status. Ensure that the
Wireless Controller Software (WCS) has been activated.
To view Wireless Access Point Settings:
1 Click Device Summary > Wireless. The Wireless Page opens:
Figure 19 Wireless Page
The Wireless Page contains the following fields:
■ Display — Displays access points according to categories. The
possible field values are:
■ Discovered APs — Displays the discovered access points.
■ Activated APs — Displays the activated access points.
■ All — Displays the access points on the network.
■ Name — Displays the user-defined access point name.
■ IP Address — Displays the IP Address assigned to the access point.
