132 CHAPTER 6: AGGREGATING PORTS
Defining Link
Aggregation
This section contains the following topics:
■ Configuring Link Aggregation
■ Defining LAG Membership
Configuring Link
Aggregation
The Link Aggregation Page optimizes port usage by linking a group of
ports together to form a single LAG. Aggregating ports multiplies the
bandwidth between the devices, increases port flexibility, and provides
link redundancy.
To view Link Aggregation:
1 Click Wired Ports > Link Aggregation > Summary. The “Link
Aggregation Summary Page” opens:
Figure 63 Link Aggregation Summary Page
The Link Aggregation Summary Page includes the following pages:
■ LAG — Displays the LAG for which the link aggregation parameters
are defined.
■ Description — Displays a description of the configured LAG.
■ Type — Displays the current LAG type.
■ Status — Indicates the LAG status. The possible fields values are:
