Physical 309
Physical
Electrical
Width 44.0 cm (17.3 in.)
Length 41.5 cm (16.3 in.)
Height 4.4 cm (1.75 in.) or 1U.
Weight 5.9 kg (13.0 lb)
Mounting Free-standing, or 19 in. rack-mounted using the
supplied mounting kit
Power Inlet IEC 320
AC Line Frequency 50/60 Hz (±3 Hz)
Input Voltage 100–240 Vac (auto range)
Current Rating 8 Amp (maximum)
Maximum Power
Consumption
465 Watts
Maximum Power
Dissipation
207 BTU/hr
PoE Maximum Output
Power per Port
15.4 watts
Power can also be provided by the switch through any
of its 24 Ethernet ports based on the IEEE 802.3af
Power over Ethernet (PoE) specifications. For PoE to
work, the receiving device must be PoE-compliant.
