Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16ACS800-compatible fault word 1.
The bit assignments of this word correspond to FAULT
WORD 1 in the ACS800. Parameter 4.120 Fault/Warning
word compatibility determines whether the bit assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each bit can indicate several ACS880 events as listed
below.
This parameter is read-only.
ACS880
events indic-
ated by this bit
(see Fault tra-
cing (page 537))
ACS880 fault nameBit
(4.120 =
ACS800 Sys-
tem ctrl pro-
gram)
(4.120 =
ACS800 Stand-
ard ctrl pro-
gram)
2340
SHORT CIRCSHORT CIRC0
2310
OVERCUR-
RENT
OVERCUR-
RENT
1
3210
DC OVER-
VOLT
DC OVER-
VOLT
2
2381, 4210,
4290, 42F1,
4310, 4380
ACS800 TEMPACS800 TEMP3
2330, 2392,
3181
EARTH FAULTEARTH FAULT4
4981, 4991,
4992, 4993
MOTOR TEMP
M
THERMISTOR5
4982
MOTOR TEMPMOTOR TEMP6
6481, 6487,
64A1, 64A2,
64A3, 64B1,
64E1, 6881,
6882, 6883,
6885
SYS-
TEM_FAULT
SYS-
TEM_FAULT
7
-UNDERLOADUNDERLOAD8
7310
OVERFREQOVERFREQ9
9081
MPROT
SWITCH
Reserved10
7582
CH2 COMM
LOSS
Reserved11
2340 (XXYY
YY01)
SC (INU1)Reserved12
2340 (XXYY
YY02)
SC (INU2)Reserved13
2340 (XXYY
YY03)
SC (INU3)Reserved14
2340 (XXYY
YY04)
SC (INU4)Reserved15
Fault word 14.21
146 Parameters
