Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
0 / uint16Selects the hexadecimal code of an event (warning, fault
or pure event) whose status is shown as bit 0 of 4.40 Event
word 1. The event codes are listed in chapter Fault
tracing (page 537).
Event word 1 bit 0
code
4.41
1 = 1Code of event.0000…FFFFh
0000 0000h / uint32Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of
this parameter.
With a value of 0000 0000h, the event word will indicate
the event regardless of the auxiliary code.
Event word 1 bit 0 aux
code
4.42
1 = 1Code of warning, fault or pure event.0000 0000h…FFFF
FFFFh
0000h / uint16Selects the hexadecimal code of an event (warning, fault
or pure event) whose status is shown as bit 1 of 4.40 Event
word 1. The event codes are listed in chapter Fault
tracing (page 537).
Event word 1 bit 1
code
4.43
1 = 1Code of event.0000…FFFFh
0000 0000h / uint32Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of
this parameter.
With a value of 0000 0000h, the event word will indicate
the event regardless of the auxiliary code.
Event word 1 bit 1 aux
code
4.44
1 = 1Code of warning, fault or pure event.0000 0000h…FFFF
FFFFh
…………
0000h / uint16Selects the hexadecimal code of an event (warning, fault
or pure event) whose status is shown as bit 15 of 4.40
Event word 1. The event codes are listed in chapter Fault
tracing (page 537).
Event word 1 bit 15
code
4.71
1 = 1Code of event.0000…FFFFh
0000 0000h / uint32Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of
this parameter.
With a value of 0000 0000h, the event word will indicate
the event regardless of the auxiliary code.
Event word 1 bit 15
aux code
4.72
1 = 1Code of warning, fault or pure event.0000 0000h…FFFF
FFFFh
ACS800 Standard ctrl
program / uint16
Selects whether the bit assignments of parameters
4.21…4.32 correspond to the ACS800 Standard control
program or the ACS800 System control program.
Fault/Warning word
compatibility
4.120
Parameters 151
