Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16ACS800-compatible warning (alarm) word 2.
The bit assignments of this word correspond to ALARM
WORD 2 in the ACS800. Parameter 4.120 Fault/Warning
word compatibility determines whether the bit assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each may indicate several ACS880 warnings as listed
below.
This parameter is read-only.
ACS880
events indic-
ated by this bit
(see Fault tra-
cing (page 537))
ACS800 alarm name
Bit
(4.120 =
ACS800 Sys-
tem ctrl pro-
gram)
(4.120 =
ACS800 Stand-
ard ctrl pro-
gram)
A781
MOTOR FANReserved0
-UNDERLOADUNDERLOAD1
-INV OVER-
LOAD
Reserved2
A480
CABLE TEMPReserved3
-ENCODER
A<>B
ENCODER4
A984
FAN OVER-
TEMP
Reserved5
-ReservedReserved6
-POWFAIL FILEPOWFAIL FILE7
-POWDOWN
FILE
ALM (OS_17)8
A780
MOTOR
STALL
MOTOR
STALL
9
A8A0
AI<MIN FUNCAI < MIN
FUNC
10
A6D1, A6D2,
A7C1, A7C2,
A7CA, A7CE
COMM MOD-
ULE
Reserved11
-BATT FAIL-
URE
Reserved12
A7EE
PANEL LOSSPANEL LOSS13
A3A2
DC UNDER-
VOLT
Reserved14
-RESTARTEDReserved15
Warning word 24.32
- / uint16User-defined event word. This word collects the status of
the events (warnings, faults or pure events) selected by
parameters 4.41…4.72.
For each event, an auxiliary code can optionally be
specified for filtering.
This parameter is read-only.
Event word 14.40
1 = Event selected by parameters 4.41 (and 4.42 is active
User bit 0b0
1 = Event selected by parameters 4.43 (and 4.44) is active
User bit 1b1
1 = Event selected by parameters 4.71 (and 4.72) is active
User bit 15b15
1 = 10000h…FFFFh
150 Parameters
