- / uint16ACS800-compatible warning (alarm) word 1.
The bit assignments of this word correspond to ALARM
WORD 1 in the ACS800. Parameter 4.120 Fault/Warning
word compatibility determines whether the assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each may indicate several ACS880 warnings as listed
below.
This parameter is read-only.
ACS880
events indic-
ated by this bit
(see Fault tra-
cing (page 537))
ACS800 alarm name
Bit
(4.120 =
ACS800 Sys-
tem ctrl pro-
gram)
(4.120 =
ACS800 Stand-
ard ctrl pro-
gram)
A5A0
START INHIB-
IT
START INHIB-
IT
0
AFE1, AFE2
EM STOPReserved1
A491, A497,
A498, A499
MOTOR TEMP
M
THERMISTOR2
A492
MOTOR TEMPMOTOR TEMP3
A2BA, A4A9,
A4B0, A4B1,
A4F6
ACS800 TEMPACS800 TEMP4
A797, A7B0,
A7B1, A7E1
ENCODER
ERR
ENCODER
ERR
5
A490, A5EA,
A782, A8A0
T MEAS CIRCT MEAS ALM6
-DIGITAL IOReserved7
-ANALOG IOReserved8
-EXT DIGITAL
IO
Reserved9
A6E5, A7AA,
A7AB
EXT ANALOG
IO
Reserved10
A7CB, AF80
CH2 COMM
LOSS
Reserved11
A981
MPROT
SWITCH
COMM MOD-
ULE
12
-EM STOP DECReserved13
A2B3
EARTH FAULTEARTH FAULT14
A983
SAFETY
SWITC
Reserved15
