Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16
(Only visible when supply unit control activated by 95.20)
Shows the control word sent to the supply unit from the
INU-LSU (inverter unit/supply unit) state machine.
This parameter is read-only.
Internal state machine
LSU CW
6.39
1 = Start charging
0 = Open main contactor (switch power off)
ON/OFFb0
0 = Emergency stop (Off2)OFF 2b1
0 = Emergency stop (Off3)OFF 3b2
1 = Start modulating
0 = Stop modulating
STARTb3
ReservedNot In Useb4
ReservedNot In Useb5
ReservedNot In Useb6
0→1 = Reset an active fault. A fresh start command is
required after reset.
RESETb7
ReservedNot In Useb8
ReservedNot In Useb9
ReserveNot In Useb10
ReservedNot In Useb11
See parameter 6.40 LSU CW user bit 0 selection.
USER BIT 0b12
See parameter 6.41 LSU CW user bit 1 selection.
USER BIT 1b13
See parameter 6.42 LSU CW user bit 2 selection.
USER BIT 2b14
See parameter 6.43 LSU CW user bit 3 selection.
USER BIT 3b15
1 = 10000h…FFFFh
MCW user bit 0 /
uint32
(Only visible when supply unit control activated by 95.20)
Selects a binary source whose status is transmitted as bit
12 of 6.39 Internal state machine LSU CW to the supply
unit.
LSU CW user bit 0
selection
6.40
00FALSE
11TRUE
2
Bit 12 of 6.1 Main control word (page 155).
MCW user bit 0
3
Bit 13 of 6.1 Main control word (page 155).
MCW user bit 1
4
Bit 14 of 6.1 Main control word (page 155).
MCW user bit 2
5
Bit 15 of 6.1 Main control word (page 155).
MCW user bit 3
See Terms and abbreviations (page 132).
Other [bit]
MCW user bit 1 /
uint32
(Only visible when supply unit control activated by 95.20)
Selects a binary source whose status is transmitted as bit
13 of 6.39 Internal state machine LSU CW to the supply
unit.
LSU CW user bit 1
selection
6.41
00FALSE
11TRUE
162 Parameters
