Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Ext run enable / uint32Selects a binary source whose status is transmitted as bit
12 of 6.11 Main status word.
MSW bit 12 sel6.31
00False
11True
2
Inverted bit 5 of 6.18 Start inhibit status word (page 157).
Ext run enable
See Terms and abbreviations (page 132).
Other [bit]
False / uint32Selects a binary source whose status is transmitted as bit
13 of 6.11 Main status word.
MSW bit 13 sel6.32
00False
11True
See Terms and abbreviations (page 132).
Other [bit]
False / uint32Selects a binary source whose status is transmitted as bit
14 of 6.11 Main status word.
MSW bit 14 sel6.33
00False
11True
See Terms and abbreviations (page 132).
Other [bit]
- / uint16
(Only visible when supply unit control activated by 95.20)
Shows the status of the supply unit.
See also section Control of a supply unit (LSU) (page 45),
and parameter group 60 DDCS communication.
This parameter is read-only.
LSU Status Word6.36
1 = Ready to switch onReady onb0
1 = Ready to operate, DC link chargedReady runb1
1 = Operation enabledReady refb2
1 = A fault is activeTrippedb3
ReservedNot In Useb4
ReservedNot In Useb5
ReservedNot In Useb6
1 = A warning is activeWarningb7
1 = The supply unit is modulatingModulatingb8
1 = Remote control (EXT1 or EXT2)
0 = Local control
Remoteb9
1 = Supply network voltage OKNet okb10
Selectable in supply control programUser bit 0b11
Selectable in supply control programUser bit 1b12
Selectable in supply control programUser bit 2b13
1 = Charging circuit active
0 = Charging circuit inactive
Chargingb14
Selectable in supply control programUser bit 3b15
1 = 10000h…FFFFh
Parameters 161
