Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = Motor identification (ID) run has been performedIdentification run doneb0
1 = The motor has been magnetizedMagnetizedb1
1 = Torque control mode activeTorque controlb2
1 = Speed control mode activeSpeed controlb3
ReservedVoltage controlb4
1 = A “safe” reference is being applied by functions such
as parameters 49.5 and 50.2.
Safe reference activeb5
1 = A “last speed” reference is being applied by functions
such as parameters 49.5 and 50.2.
Last speed activeb6
1 = Reference signal lostLoss of referenceb7
1 = Emergency stop failed (see parameters 31.32 and
31.33).
Emergency stop failedb8
1 = Jogging enable signal is onJogging activeb9
1 = Actual speed, frequency or torque equals or exceeds
limit (defined by parameters 46.31…46.33). Valid in both
directions of rotation.
Above limitb10
1 = An emergency stop command signal is active, or the
drive is stopping after receiving an emergency stop
command.
Emergency stop
active
b11
1 = Reduced run active (see section Reduced run
function (page 105)).
Reduced runb12
Reservedb13
1 = Stopping failed (see parameters 31.37 and 31.38)
Stop failedb14
Reservedb15
1 = 10000h…FFFFh
- / uint16Start inhibit status word. This word specifies the source of
the inhibiting condition that is preventing the drive from
starting.
After the condition is removed, the start command must
be cycled. See bit-specific notes.
See also parameter 6.25 Drive inhibit status word 2, and
6.16 Drive status word 1, bit 1.
This parameter is read-only.
Note:
•
If bit 1 of 6.16 Drive status word 1 is still set after the
removal of the inhibiting condition, and edge triggering
is selected for the active external control location, a
fresh rising-edge start signal is required. See
parameters 20.2, 20.7 and 20.19.
•
If bit 1 of 6.16 Drive status word 1 is still set after the
removal of the inhibiting condition, a fresh rising-edge
start signal is required.
• Informative bit. The inhibiting condition need not be
removed by the user.
Start inhibit status
word
6.18
