Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
15The start and stop commands are taken from another drive
through the master/follower link.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.2 Ext1 start trigger type.
M/F link
21The start and stop commands are taken from the
application program control word (parameter 6.2 Application
control word).
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.2 Ext1 start trigger type.
Application Program
22Reserved.ATF
16The start and stop commands are taken from an external
(DDCS) controller.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.2 Ext1 start trigger type.
DDCS controller
Edge / uint16Defines whether the start signal for external control location
EXT1 is edge-triggered or level-triggered.
Note: This parameter is only effective when parameter
20.1 Ext1 commands is set to In1 Start, In1 Start; In2 Dir,
In1 Start fwd; In2 Start rev, or Control panel.
Ext1 start trigger type20.2
0The start signal is edge-triggered.Edge
1The start signal is level-triggered.Level
DI1 / uint32
Selects source 1 for parameter 20.1 Ext1 commands.
Ext1 in1 source20.3
00 (always off).Not selected
11 (always on).Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
See Terms and abbreviations (page 132).
Other [bit]
DI2 / uint32
Selects source 2 for parameter 20.1 Ext1 commands.
For the available selections, see parameter 20.3 Ext1 in1
source.
Ext1 in2 source20.4
Not selected / uint32
Selects source 3 for parameter 20.1 Ext1 commands.
For the available selections, see parameter 20.3 Ext1 in1
source.
Ext1 in3 source20.5
Not selected / uint16Selects the source of start, stop and direction commands
for external control location 2 (EXT2).
See also parameters 20.7…20.10.
Ext2 commands20.6
0No start or stop command sources selected.Not selected
Parameters 243
