Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = Minimum limit supervision of AI1 active.AI1 < MINb0
1 = Maximum limit supervision of AI1 active.AI1 > MAXb1
1 = Minimum limit supervision of AI2 active.AI2 < MINb2
1 = Maximum limit supervision of AI2 active.AI2 > MAXb3
1 = Minimum limit supervision of AI3 active.AI3 < MINb4
1 = Maximum limit supervision of AI3 active.AI3 > MAXb5
Reservedb6…15
1 = 10000h…FFFFh
No action / uint16
(Visible when 14.1 Module 1 type = FAIO-01)
Triggers the analog input tuning function, which enables
the use of actual measurements as the minimum and
maximum input values instead of potentially inaccurate
estimates.
Apply the minimum or maximum signal to the input and
select the appropriate tuning function.
See also the drawing at parameter 14.35 AI1 scaled at AI1
min.
AI tune14.21
0Tuning action completed or no action has been requested.
The parameter automatically reverts to this value after any
tuning action.
No action
1The measured value of AI1 is set as the minimum value
of AI1 into parameter 14.33 AI1 min.
AI1 min tune
2The measured value of AI1 is set as the maximum value
of AI1 into parameter 14.34 AI1 max.
AI1 max tune
3The measured value of AI2 is set as the minimum value
of AI2 into parameter 14.48 AI2 min.
AI2 min tune
4The measured value of AI2 is set as the maximum value
of AI2 into parameter 14.49 AI2 max.
AI2 max tune
No action / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Triggers the analog input tuning function, which enables
the use of actual measurements as the minimum and
maximum input values instead of potentially inaccurate
estimates.
Apply the minimum or maximum signal to the input and
select the appropriate tuning function.
See also the drawing at parameter 14.35 AI1 scaled at AI1
min.
AI tune14.21
0Tuning action completed or no action has been requested.
The parameter automatically reverts to this value after any
tuning action.
No action
1The measured value of AI1 is set as the minimum value
of AI1 into parameter 14.33 AI1 min.
AI1 min tune
2The measured value of AI1 is set as the maximum value
of AI1 into parameter 14.34 AI1 max.
AI1 max tune
3The measured value of AI2 is set as the minimum value
of AI2 into parameter 14.48 AI2 min.
AI2 min tune
