ABB ACS880 - Page 206

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
No action / uint16
(Visible when 14.1 Module 1 type = FAIO-01)
Selects how the drive reacts when an analog input signal
moves out of the minimum and/or maximum limits specified
for the input.
The inputs and the limits to be observed are selected by
parameter 12.4 AI supervision selection.
AI supervision
function
14.19
0No action taken.No action
1
Drive trips on 80A0 AI Supervision.
Fault
2
Drive generates an A8A0 AI Supervised Warning warning.
Warning
3
Drive generates a warning (A8A0 AI Supervised Warning)
and freezes the speed (or frequency) to the level the drive
was operating at. The speed/frequency is determined on
the basis of actual speed using 850 ms low-pass filtering.
WARNING!
Make sure that it is safe to continue operation in
case of a communication break.
Last speed
4
Drive generates a warning (A8A0 AI Supervised Warning)
and sets the speed to the speed defined by parameter
22.41 Speed ref safe (or 28.41 Frequency ref safe when
frequency reference is being used).
WARNING!
Make sure that it is safe to continue operation in
case of a communication break.
Speed ref safe
Input / uint16
(Visible when 14.1 Module 1 type = FIO-01)
Selects whether DIO3 of the extension module is used as
a digital input or output.
DIO3 function14.19
0DIO3 is used as a digital output.Output
1DIO3 is used as a digital input.Input
- / uint16
(Visible when 14.1 Module 1 type = FAIO-01)
Specifies the analog input limits to be supervised. See
parameter 14.19 AI supervision function.
Note: The number of active bits in this parameter depends
on the number of inputs on the extension module.
AI supervision
selection
14.20
1 = Minimum limit supervision of AI1 active.AI1 < MINb0
1 = Maximum limit supervision of AI1 active.AI1 > MAXb1
1 = Minimum limit supervision of AI2 active.AI2 < MINb2
1 = Maximum limit supervision of AI2 active.AI2 > MAXb3
Reservedb4…15
1 = 10000h…FFFFh
- / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Specifies the analog input limits to be supervised. See
parameter 14.19 AI supervision function.
AI supervision
selection
14.20
206 Parameters
