ABB ACS880 - Page 208

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
4The measured value of AI2 is set as the maximum value
of AI2 into parameter 14.49 AI2 max.
AI2 max tune
5The measured value of AI3 is set as the minimum value
of AI3 into parameter 14.63 AI3 min.
AI3 min tune
6The measured value of AI3 is set as the maximum value
of AI3 into parameter 14.64 AI3 max.
AI3 max tune
Not energized / uint32
(Visible when 14.1 Module 1 type = FIO-01)
Selects a drive signal to be connected to digital input/output
DIO3 when parameter 14.19 DIO3 function is set to Output.
For the available selections, see parameter 14.11 DIO1
output source.
DIO3 output source14.21
- / uint16
(Visible when 14.1 Module 1 type = FAIO-01)
The true readings of the analog inputs can be overridden
for eg. testing purposes. A forced value parameter is
provided for each analog input, and its value is applied
whenever the corresponding bit in this parameter is 1.
AI force selection14.22
1 = Force mode: Force AI1 to value of parameter 14.28
AI1 force data.
AI1b0
1 = Force mode: Force AI2 to value of parameter 14.43
AI2 force data.
AI2b1
Reservedb2…15
1 = 10000h…FFFFh
0.00 s / real32
(Visible when 14.1 Module 1 type = FDIO-01)
Defines the activation delay for digital input DI3. See
parameter 14.12 DI1 ON delay.
DI3 ON delay14.22
10 = 1 s / 100 = 1 sActivation delay for DI3.0.00 ... 3000.00 s
- / uint16
(Visible when 14.1 Module 1 type = FIO-11)
The true readings of the analog inputs can be overridden
for eg. testing purposes. A forced value parameter is
provided for each analog input, and its value is applied
whenever the corresponding bit in this parameter is 1.
AI force selection14.22
1 = Force mode: Force AI1 to value of parameter 14.28
AI1 force data.
AI1b0
1 = Force mode: Force AI2 to value of parameter 14.43
AI2 force data.
AI2b1
1 = Force mode: Force AI3 to value of parameter 14.58
AI3 force data (FIO-11 only).
AI3b2
Reservedb3…15
1 = 10000h…FFFFh
0.00 s / real32
(Visible when 14.1 Module 1 type = FIO-01)
Defines the activation delay for digital input/output DIO3.
See parameter 14.12 DIO1 ON delay.
DIO3 ON delay14.22
10 = 1 s / 100 = 1 sActivation delay for DIO3.0.00 ... 3000.00 s
0.00 s / real32
(Visible when 14.1 Module 1 type = FDIO-01)
Defines the deactivation delay for digital input DI3. See
parameter 14.12 DI1 ON delay.
DI3 OFF delay14.23
208 Parameters
